NIROSTAR Impeller pumpNirostar 2000-A | 2000-B | 2000-C | 2000-C PLUS | 2000-D | 2000-E | 2000-F

Art. Nr. 13118116322

Impellerpump
flow rate max. litres 15 l/min
flow rate max. m³ 0,9 m³/h
max. pressure 4 bar
Inlet/outlet ¾" mt
Impeller Perbunan® (NBR) , Bush material stainless steel (1.4404)
Shaft sealing ring Perbunan® (NBR)
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 3,2 A
Starting capacitor 40 µF, Operating capacitor 16 µF
rotation max. 1400 min-1
Material motorshaft 1.4104
Protection class IP55
weight 9,8 kg

Art. Nr. 13118117322

Impellerpumpe
flow rate max. litres 15 l/min
flow rate max. m³ 0,9 m³/h
max. pressure 4 bar
Inlet/outlet ¾" aG
Impeller Perbunan® (NBR) , Bush material stainless steel (1.4404)
Shaft sealing ring Perbunan® (NBR)
Material pump housing Edelstahl 1.4404

Motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 1,15 A
rotation max. 1400 min-1
Protection class IP55
Material motorshaft 1.4404

Frequency converter suitable

Art. Nr. 13118116321

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 5 bar
Inlet/outlet ¾" mt
Impeller Perbunan® (NBR) , Bush material stainless steel (1.4404)
Shaft sealing ring Perbunan® (NBR)
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 3,2 A
Starting capacitor 40 µF
Operating capacitor 20 µF
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP55
weight 9,8 kg

Art. Nr. 13118117321

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 5 bar
Inlet/outlet ¾" mt
Impeller Perbunan® (NBR) , Bush material stainless steel (1.4404)
Shaft sealing ring Perbunan® (NBR)
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 1,1 A
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP55
weight 9,8 kg

Art. Nr. 13118127221

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 5 bar
Inlet/outlet 3/4" mt
Impeller Perbunan® (NBR) , Bush material stainless steel (1.4404)
Shaft sealing ring EPDM® with o-ring instead of spring
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 1,20 A
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP66 , Operating mode S1

Equipment/Accessories :
- Control Unit in pressure-resistant housing, 400 V
f. NIROSTAR 2000-A/B ATEX application
- Dry run protection 60°C
- Trolley KOMPAKT

Complete unit ATEX class EX II 2/2G Ex IIB T3

Dimensions 760-1000-1100x490x510 mm
weight 46,5 kg

Art. Nr. 13118126921

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 5 bar
Inlet/outlet 3/4" mt
Impeller Perbunan® (NBR) , Bush material stainless steel (1.4404)
Shaft sealing ring EPDM® mit O-Ring statt Feder
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 2,56 A
Starting capacitor 50 µF, Operating capacitor 16 µF
rotation max. 2860 min-1
Material motorshaft Hardened shaft 1.4028 (AISI420F)
Protection class IP66 , Operating mode S1

Equipment/Accessories :
- Control Unit in pressure-resistant housing, 230 V
f. NIROSTAR 2000-A/B ATEX application
- Dry run protection 60°C
- Trolley KOMPAKT

Complete unit ATEX class EX II 2/2G Ex IIB T3

Dimensions 760-1000-1100x490x510 mm
weight 46,5 kg

Art. Nr. 13118117422A

Impellerpumpe
flow rate max. litres 15 l/min
flow rate max. m³ 0,9 m³/h
max. pressure 4 bar
Inlet/outlet ¾" aG
Impeller Perbunan® (NBR) , Bush material stainless steel (1.4404)
Shaft sealing ring Perbunan® (NBR)
Material pump housing Edelstahl 1.4404
With pump carrier

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 1,15 A
rotation max. 1400 min-1
Material motorshaft 1.4104
Protection class IP55
weight 9,8 kg

Art. Nr. 13118112412A

Impellerpump
flow rate max. litres 15 l/min
flow rate max. m³ 0,9 m³/h
max. pressure 5 bar
Inlet/outlet ¾" mt
Impeller Perbunan® (NBR) , Bush material stainless steel (1.4404)
Shaft sealing ring Perbunan® (NBR)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor CEM
Voltage (DC) 24 V
Nominal power 0,25 kW, Rated current (DC) 16 A
rotation max. 1500 min-1
Motorshaft N-WE 14x30mm
Protection class IP55 , Operating mode S1
Electrical connection Control board
Colour RAL 9005 black
weight 10 kg

Art. Nr. 13118126421A

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 5 bar
Inlet/outlet 3/4" mt
Impeller Perbunan® (NBR) , Bush material stainless steel (1.4404)
Shaft sealing ring EPDM
Material pump housing stainless steel 1.4404, aluminium AlMgSi1
With pump carrier

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 3,8 A
Starting capacitor 40 µF
Operating capacitor 12,5 µF
rotation max. 1400 min-1
Material motorshaft 1.4104
Protection class IP55

weight 9,8 kg

Art. Nr. 13118112531A

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 5 bar
Inlet/outlet ¾" mt
Impeller Perbunan® (NBR) , Bush material stainless steel (1.4404)
Shaft sealing ring Perbunan® (NBR)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor
Voltage (DC) 24 V
Nominal power 0,35/0,5 kW, Rated current (DC) 21/30 A
rotation max. 3000 min-1
Motorshaft N-WE 11x30
Protection class IP44 , Operating mode S2
Electrical connection Control board
weight 10 kg

Art. Nr. 13148132411A

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 4 bar
Inlet/outlet ¾" mt
Impeller Neoprene® (CR) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor CEM
Voltage (DC) 24 V
Nominal power 0,25 kW, Rated current (DC) 12 A
rotation max. 3000 min-1
Motorshaft N-WE 14x30mm
Protection class IP55 , Operating mode S1
Electrical connection Control board
Without cable and plug
Colour RAL 9005 black
weight 10,00 kg

Art. Nr. 13118132531A

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 5 bar
Inlet/outlet ¾" mt
Impeller Perbunan® (NBR) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor
Voltage (DC) 24 V
Nominal power 0,35/0,5 kW, Rated current (DC) 21/30 A
rotation max. 3000 min-1
Motorshaft N-WE 11x30
Protection class IP44 , Operating mode S2
Electrical connection Control board
weight 10 kg

Art. Nr. 13118132411A

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 5 bar
Inlet/outlet ¾" mt
Impeller Perbunan® (NBR) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor CEM
Voltage (DC) 24 V
Nominal power 0,25 kW, Rated current (DC) 12 A
rotation max. 3000 min-1
Motorshaft N-WE 14x30mm
Protection class IP55 , Operating mode S1
Electrical connection Control board
Colour RAL 9005 black
weight 10 kg

Art. Nr. 13218116332

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 4 bar
Inlet/outlet 1" mt
Impeller Perbunan® (NBR) , Bush material stainless steel (1.4404)
Shaft sealing ring Perbunan® (NBR)
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 230 V,Nominal frequency 50 Hz
Nominal power 0,55 kW,Rated current (AC) 3,8 A
Starting capacitor 40 µF,Operating capacitor 16 µF
rotation max. 1400 min-1
Material motorshaft 1.4404
Protection class IP55
Motor protection (thermal) 130

Art. Nr. 13218127231

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 5 bar
Inlet/outlet 1 " mt
Impeller Perbunan® (NBR) , Bush material stainless steel (1.4404)
Shaft sealing ring EPDM® with o-ring instead of spring
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 1,45 A
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP66 , Operating mode S1

Equipment/Accessories :
- Control Unit in pressure-resistant housing, 400 V
f. NIROSTAR 2000-A/B ATEX application
- Dry run protection 60°C
- Trolley KOMPAKT

Complete unit ATEX class EX II 2/2G Ex IIB T3

Dimensions 760-1000-1100x490x510 mm
weight 47,00 kg

Art. Nr. 13218126931

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 5 bar
Inlet/outlet 1 " mt
Impeller Perbunan® (NBR) , Bush material stainless steel (1.4404)
Shaft sealing ring EPDM mit O-Ring statt Feder
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 3,8 A
Starting capacitor 70 µF, Operating capacitor 30 µF
rotation max. 2800 min-1
Material motorshaft 1.4028 (AISI420F)
Protection class IP66 , Operating mode S1

Equipment/Accessories :
- Control Unit in pressure-resistant housing, 230 V
f. NIROSTAR 2000-A/B ATEX application
- Dry run protection 60°C
- Trolley KOMPAKT

Complete unit ATEX class EX II 2/2G Ex IIB T3

Dimensions 760-1000-1100x490x510 mm
weight 47,00 kg

Art. Nr. 13218116432A

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 4 bar
Inlet/outlet 1" mt
Impeller Perbunan® (NBR) , Bush material stainless steel (1.4404)
Shaft sealing ring Perbunan® (NBR)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 3,8 A
Starting capacitor 40 µF, Operating capacitor 16 µF
rotation max. 1400 min-1
Material motorshaft 1.4104
Protection class IP55
Motor protection (thermal) 130
weight 11 kg

Art. Nr. 13218112421A

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 5 bar
Inlet/outlet 1" mt
Impeller Perbunan® (NBR) , Bush material stainless steel (1.4404)
Shaft sealing ring Perbunan® (NBR)
Material pump housing Edelstahl 1.4404
With pump carrier

Electric motor CEM
Voltage (DC) 24 V
Nominal power 0,37 kW, Voltage (DC) 24 V
rotation max. 3000 min-1
Motorshaft N-WE 14x30mm
Protection class IP55 , Operating mode S1
Electrical connection Control board
weight 10,6 kg

Art. Nr. 13218132531A

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 3 bar
Inlet/outlet 1" mt
Impeller Perbunan® (NBR) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor
Voltage (DC) 24 V
Nominal power 0,6/0,8 kW, Rated current (DC) 36/47 A
rotation max. 3000 min-1
Motorshaft N-WE 14x30
Protection class IP44 , Operating mode S2
Electrical connection Control board
weight 10,6 kg

Art. Nr. 13211132421A

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 5 bar
Inlet/outlet 1" mt
Impeller Perbunan® (NBR) , Bush material Polyamid
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor CEM
Voltage (DC) 24 V
Nominal power 0,37 kW, Rated current (DC) 17 A
rotation max. 3000 min-1
Motorshaft N-WE 14x30mm
Protection class IP55 , Operating mode S1
Electrical connection Control board
Colour RAL 9005 black
weight 10,5 kg

Art. Nr. 13318256352

Impellerpump
flow rate max. litres 120 l/min
flow rate max. m³ 7,2 m³/h
max. pressure 2,0 bar
Inlet/outlet 1 ¼“ mt
Impeller Perbunan® (NBR) , Bush material stainless steell (1.4404)
Mechanical seal Car/Cer/Viton
Material pump housing stainless steell 1.4404
With swing stopper and fixing screw

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,90 kW, Rated current (AC) 6,2 A
Starting capacitor 70 µF, Operating capacitor 30 µF
rotation max. 1400 min-1
Material motorshaft 1.4404
Protection class IP55
Rotation direction left/right , Switch L/R
weight 17,2 kg

Art. Nr. 13318257342

Impellerpump
flow rate max. litres 120 l/min
flow rate max. m³ 7,2 m³/h
max. pressure 2,0 bar
Inlet/outlet 1 ¼“ mt
Impeller Perbunan® (NBR) , Bush material stainless steell (1.4404)
Mechanical seal Car/Cer/Viton
Material pump housing stainless steell 1.4404
With swing stopper and fixing screw

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,75 kW, Rated current (AC) 3,03 A
rotation max. 1400 min-1
Material motorshaft 1.4404
Protection class IP55 , IE3
Rotation direction left/right , Switch L/R
weight 17,7 kg

Art. Nr. 13318256533

Impellerpump
flow rate max. litres 80 l/min
flow rate max. m³ 4,8 m³/h
max. pressure 2,0 bar
Inlet/outlet 1 ¼“ mt
Impeller Perbunan® (NBR) , Bush material stainless steell (1.4404)
Mechanical seal Car/Cer/Viton
Material pump housing stainless steell 1.4404
With swing stopper and fixing screw

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 4,4 A
Starting capacitor 70 µF, Operating capacitor 16 µF
rotation max. 900 min-1
Material motorshaft 1.4404
Protection class IP55
Rotation direction left/right , Switch L/R
weight 17,2 kg

Art. Nr. 13318257543

Impellerpump
flow rate max. litres 80 l/min
flow rate max. m³ 4,8 m³/h
max. pressure 2,0 bar
Inlet/outlet 1 ¼“ mt
Impeller Perbunan® (NBR) , Bush material stainless steell (1.4404)
Mechanical seal Car/Cer/Viton
Material pump housing stainless steell 1.4404
With swing stopper and fixing screw

Electric motor
rotation max. 900 min-1, Nominal frequency 50 Hz
Nominal power 0,75 kW, Rated current (AC) 2,1 A
rotation max. 900 min-1
Material motorshaft 1.4404
Protection class IP55 , IE3
Rotation direction left/right , Switch L/R
weight 17,7 kg

Art. Nr. 190016

Impellerpump
flow rate max. litres 80 l/min
flow rate max. m³ 4,8 m³/h
max. pressure 2,4 bar
Inlet/outlet 1 1/4" mt
Impeller Perbunan® (NBR)
Mechanical seal Perbunan® (NBR)
Material pump housing stainless steel 1.4401

Electric motor
Voltage (DC) 24 V
Nominal power 0,5 kW, Rated current (DC) 30 A
rotation max. 1100 min-1
Operating mode S1 , Protection class IP44
Rotation direction left/right
Electrical connection Control board , without cable and plug
weight 15 kg

Art. Nr. 190010

Impellerpump
flow rate max. litres 96 l/min
flow rate max. m³ 5,76 m³/h
max. pressure 3,0 bar
Inlet/outlet 1¼" mt
Impeller Perbunan® (NBR)
Mechanical seal Perbunan® (NBR)
Material pump housing stainless steel 1.4401

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,75 kW, Rated current (AC) 7,1 A
rotation max. 1400 min-1
Switch L/R , 2 m cable with plug
Protection class IP55
weight 16 kg

Art. Nr. 190011

Impellerpump
flow rate max. litres 96 l/min
flow rate max. m³ 5,76 m³/h
max. pressure 3,0 bar
Inlet/outlet 1¼" mt
Impeller Perbunan® (NBR)
Mechanical seal Perbunan® (NBR)
Material pump housing stainless steel 1.4401

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,75 kW, Rated current (AC) 2,1 A
rotation max. 1400 min-1
Switch L/R , 4 m cable without plug
Protection class IP55
weight 13 kg

Art. Nr. 190018

Impellerpump
flow rate max. litres 64 l/min
flow rate max. m³ 3,84 m³/h
max. pressure 3,0 bar
Inlet/outlet 1¼" mt
Impeller Perbunan® (NBR)
Mechanical seal Perbunan® (NBR
Material pump housing stainless steel 1.4401

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,56 kW, Rated current (AC) 5,0 A
rotation max. 900 min-1
Switch L/R , 2 m cable with plug
Protection class IP55
weight 15 kg

Art. Nr. 190017

Impellerpump
flow rate max. litres 64 l/min
flow rate max. m³ 3,84 m³/h
max. pressure 3,0 bar
Inlet/outlet 1¼" mt
Impeller Perbunan® (NBR)
Mechanical seal Perbunan® (NBR)
Material pump housing stainless steel 1.4401

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,56 kW, Rated current (AC) 1,7 A
rotation max. 900 min-1
Switch L/R , 4 m cable without plug
Protection class IP55
weight 14 kg

Art. Nr. 19003023

Impellerpump
flow rate max. litres 166 l/min
flow rate max. m³ 9,96 m³/h
max. pressure 3 bar
Inlet/outlet 1 ½“ mt
impeller Perbunan® (NBR)
Mechanical seal Viton® (FKM)
Material pump housing stainless steel 1.4301

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 1,5 kW, Rated current (AC) 3,8 A
rotation max. 1400 min-1
Switch L/R , 4 m cable without plug
Protection class IP55
weight 19 kg

Art. Nr. 190030

Impellerpump
flow rate max. litres 166 l/min
flow rate max. m³ 9,96 m³/h
max. pressure 3,0 bar
Inlet/outlet 1½" mt
Impeller Perbunan® (NBR)
Mechanical seal Perbunan® (NBR)
Material pump housing stainless steel 1.4301

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 1,5 kW, Rated current (AC) 3,8 A
rotation max. 1400 min-1
Switch L/R , 4 m cable without plug
Protection class IP55
weight 18 kg

Art. Nr. 190020

Impellerpump
flow rate max. litres 115 l/min
flow rate max. m³ 6,9 m³/h
max. pressure 3,0 bar
Inlet/outlet 1½" mt
Impeller Perbunan® (NBR)
Mechanical seal Perbunan® (NBR)
Material pump housing stainless steel 1.4301

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 1,5 kW, Rated current (AC) 7,9 A
rotation max. 900 min-1
Switch L/R , 2 m cable with plug
Not suitable for bi-directional use!
Protection class IP55
weight 20,5 kg

Art. Nr. 19003123

Impellerpump
flow rate max. litres 115 l/min
flow rate max. m³ 6,9 m³/h
max. pressure 3,0 bar
Inlet/outlet 1 ½“ mt
Impeller Perbunan® (NBR) ,
Mechanical seal Widia/Widia/Viton
Material pump housing stainless steel 1.4301

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 1,5 kW, Rated current (AC) 4,1 A
rotation max. 900 min-1
Switch L/R , 4 m cable without plug
Protection class IP55
weight 19 kg

Art. Nr. 190031

Impellerpump
flow rate max. litres 115 l/min
flow rate max. m³ 6,9 m³/h
max. pressure 3,0 bar
Inlet/outlet 1½" mt
Impeller Perbunan® (NBR)
Mechanical seal Perbunan® (NBR)
Material pump housing stainless steel 1.4301

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 1,5 kW, Rated current (AC) 4,1 A
rotation max. 900 min-1
Switch L/R , 4 m cable without plug
Protection class IP55
weight 20 kg

Art. Nr. 190041

Impellerpump
flow rate max. litres 375 l/min
flow rate max. m³ 22,5 m³/h
max. pressure 1,6 bar
Inlet/outlet 2" mt
Impeller Perbunan® (NBR)
Mechanical seal Perbunan® (NBR)
Material pump housing stainless steell 1.4301

Hydraulic motor
rotation max. 175 - 900 min-1
Oil quantity 0,05 l per rotation (45 l/min. for 900 rotations)
oil pressure 100 - 120 bar
weight 14,5 kg

Art. Nr. 190080

Impellerpump
flow rate max. litres 375 l/min
flow rate max. m³ 22,5 m³/h
max. pressure 2,0 bar
Inlet/outlet 2" mt
Impeller Perbunan® (NBR)
Mechanical seal Perbunan® (NBR)
Material pump housing stainless steel 1.4301

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 1,87 kW, Rated current (AC) 5,5 A
rotation max. 900 min-1
Switch L/R , 4 m cable without plug
Protection class IP55
weight 30 kg

Art. Nr. 190042

Impellerpump
flow rate max. litres 730 l/min
flow rate max. m³ 43,8 m³/h
max. pressure 1,8 bar
Inlet/outlet 3" mt
Impeller Perbunan® (NBR)
Mechanical seal Perbunan® (NBR)
Material pump housing stainless steel 1.4301

Hydraulic motor
rotation max. 150 - 600 min-1
Oil quantity 0,05 l per rotation (30 l/min. for 600 rotations)
Oil pressure 100 - 120 bar
weight 23 kg

Art. Nr. 190090

Impellerpump
flow rate max. litres 600 l/min
flow rate max. m³ 36 m³/h
max. pressure 2,0 bar
Inlet/outlet 3" mt
Impeller Perbunan® (NBR)
Mechanical seal Perbunan® (NBR)
Material pump housing stainless steel 1.4301

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 3,3 kW, Rated current (AC) 9,5 A
rotation max. 470 min-1, Protection class IP55
Electrical connection Control board
Without cable and plug
weight 72 kg

Art. Nr. 190091

Impellerpump
flow rate max. litres 730 l/min
flow rate max. m³ 43,8 m³/h
max. pressure 2,0 bar
Inlet/outlet 3" mt
Impeller Perbunan® (NBR)
Mechanical seal Perbunan® (NBR)
Material pump housing stainless steel 1.4301

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 3,5 kW, Rated current (AC) 8,2 A
rotation max. 600 min-1, Protection class IP55
Electrical connection Control board , without cable and plug
weight 70 kg

Art. Nr. 190068

Impellerpump
flow rate max. litres 730 l/min
flow rate max. m³ 43,8 m³/h
max. pressure 2 bar
Inlet/outlet 3" mt
Impeller Perbunan® (NBR)
Mechanical seal Perbunan® (NBR)
Material pump housing stainless steel 1.4301
Pump and frequency converter mounted on pump trolley, incl. dry run protection

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 3,5 kW, Rated current (AC) 8,2 A
rotation max. 50 - 600 min-1
With cable remote control (15 m cable)
With feeding cable to control box lenght about 10 m
Lenght of connection cable motor/control box about 1,5 m
Protection class IP55
weight 97 kg

Art. Nr. 190094

Impellerpump
flow rate max. litres 410 l/min
flow rate max. m³ 24,6 m³/h
max. pressure 1,8 bar
Inlet/outlet 3" mt
Impeller Perbunan® (NBR)
Mechanical seal Perbunan® (NBR)
Material pump housing stainless steel 1.4301

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 4,0 kW, Rated current (AC) 7,65 A
rotation max. 300 min-1
mit Klemmbrett
Control box CE with dry run protection
weight 69 kg

Art. Nr. 13148126321

Motor: 230 volt 50 Hz, 3,2 A
0,37 Kw, 2720 rpm , IP: 55, 10,2 kg
Pump: max. 30 Liter/Min., max. 4 bar
Connections ¾" external thread
Impeller Neoprene®
Shaft seal ring EPDM
Pump body stainless steel
Pump flanged directly to shaft
Star handles for quick opening.

Art. Nr. 13148136322

Impellerpump
flow rate max. litres 15 l/min
flow rate max. m³ 0,9 m³/h
max. pressure 4 bar
Inlet/outlet 3/4" mt
Impeller Neoprene® (CR) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 3,2 A
Starting capacitor 40 µF
Operating capacitor 16 µF
rotation max. 1400 min-1
Material motorshaft 1.4104
Protection class IP55

Art. Nr. 13148137322

Impellerpump
flow rate max. litres 15 l/min
flow rate max. m³ 0,9 m³/h
max. pressure 4 bar
Inlet/outlet 3/4" mt
Impeller Neoprene® (CR) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 1,15 A
rotation max. 1400 min-1
Material motorshaft 1.4404
Protection class IP55
weight 9,8 kg

Art. Nr. 13148136321

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 4 bar
Inlet/outlet 3/4" mt
Impeller Neoprene® (CR) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 3,2 A
Starting capacitor 40 µF
Operating capacitor 20 µF
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP55
Motor protection (thermal) 130
weight 9,8 kg

Art. Nr. 13148137321

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 4 bar
Inlet/outlet 3/4" mt
Impeller Neoprene® (CR), Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 1,1 A
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP55
weight 9,8 kg

Art. Nr. 13149127321

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 4 bar
Inlet/outlet 3/4" mt
Impeller Neoprene® (CR) , Bush material Special bush stainless steel 1.4404
Shaft sealing ring EPDM
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 1,1 A
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP55
weight 9,8 kg

Art. Nr. 13148127321

Impellerpumpe
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 4 bar
Inlet/outlet 3/4" aG
Impeller Neoprene® (CR) , Bush material stainless steel (1.4404)
Shaft sealing ring EPDM
Material pump housing Edelstahl 1.4404

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 1,1 A
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP55
weight 9,8 kg

Art. Nr. 13148137221

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 4 bar
Inlet/outlet 3/4" mt
Impeller Neoprene® (CR) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM) with o-ring instead of spring
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 1,20 A
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP66 , Operating mode S1

Equipment/Accessories :
- Control Unit in pressure-resistant housing, 400 V
f. NIROSTAR 2000-A/B ATEX application
- Dry run protection 60°C
- Trolley KOMPAKT

Complete unit ATEX class EX II 2/2G Ex IIB T3

Dimensions 760-1000-1100x490x510 mm
weight 46,5 kg

Art. Nr. 13148136921

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 4 bar
Inlet/outlet 3/4" mt
Impeller Neoprene® (CR) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM) with o-ring instead of spring
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 2,56 A
Starting capacitor 50 µF, Operating capacitor 16 µF
rotation max. 2860 min-1
Material motorshaft Hardened shaft 1.4028 (AISI420F)
Protection class IP66 , Operating mode S1

Equipment/Accessories :
- Control Unit in pressure-resistant housing, 230 V
f. NIROSTAR 2000-A/B ATEX application
- Dry run protection 60°C
- Trolley KOMPAKT

Complete unit ATEX class EX II 2/2G Ex IIB T3

Dimensions 760-1000-1100x490x510 mm
weight 46,5 kg

Art. Nr. 13148136422A

Impellerpump
flow rate max. litres 15 l/min
flow rate max. m³ 0,9 m³/h
max. pressure 4 bar
Inlet/outlet ¾" mt
Impeller Neoprene® (CR) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 3,2 A
Starting capacitor 40 µF
Operating capacitor 16 µF
rotation max. 1400 min-1
Material motorshaft 1.4104
Protection class IP55
Motor protection (thermal) yes
weight 10 kg

Art. Nr. 13148137422A

Impellerpump
flow rate max. litres 15 l/min
flow rate max. m³ 0,9 m³/h
max. pressure 4 bar
Inlet/outlet ¾" mt
Impeller Neoprene® (CR) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 1,15 A
rotation max. 1400 min-1
Material motorshaft 1.4104
Protection class IP55
weight 10 kg

Art. Nr. 13148136421A

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 4 bar
Inlet/outlet ¾" mt
Impeller Neoprene® (CR) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 3,2 A
Starting capacitor 40 µF
Operating capacitor 12,5 µF
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP55
Motor protection (thermal) yes
weight 10 kg

Art. Nr. 13148137421A

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 4 bar
Inlet/outlet ¾" mt
Impeller Neoprene® (CR) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 1,1 A
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP55
weight 10 kg

Art. Nr. 13248136332

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 3 bar
Inlet/outlet 1" mt
Impeller Neoprene® (CR) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 3,8 A
Starting capacitor 40 µF
Operating capacitor 16 µF
rotation max. 1400 min-1
Material motorshaft 1.4404
Protection class IP55
Motor protection (thermal) 130
weight 10,3 kg

Art. Nr. 13248137332

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 4 bar
Inlet/outlet 1" mt
Impeller Neoprene® (CR) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 1,6 A
rotation max. 1400 min-1
Material motorshaft 1.4404
Protection class IP55
weight 10,4 kg

Art. Nr. 13248136331

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 4 bar
Inlet/outlet 1" mt
Impeller Neoprene® (CR) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 4,3 A
Starting capacitor 40 µF
Operating capacitor 20 µF
rotation max. 2800 min-1
Protection class IP55
Motor protection (thermal) 130
weight 10,3 kg

Art. Nr. 13248137331

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 4 bar
Inlet/outlet 1" mt
Impeller Neoprene® (CR) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 1,4 A
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP55
weight 10,4 kg

Art. Nr. 13248136931

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 4 bar
Inlet/outlet 1 " mt
Impeller Neoprene® (CR) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM) with o-ring instead of spring
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 3,8 A
Starting capacitor 70 µF, Operating capacitor 30 µF
rotation max. 2800 min-1
Material motorshaft 1.4028 (AISI420F)
Protection class IP66

Equipment/Accessories :
- Control Unit in pressure-resistant housing, 230 V
f. NIROSTAR 2000-A/B ATEX application
- Dry run protection 60°C
- Trolley KOMPAKT

Complete unit ATEX class EX II 2/2G Ex IIB T2 Gb/Gb +5°C<Ta<+40°C

Dimensions 760-1000-1100x490x510 mm
weight 46,50 kg

Art. Nr. 13248137231

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 4 bar
Inlet/outlet 1 " mt
Impeller Neoprene® (CR) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM) with o-ring instead of spring
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 1,45 A
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP66

Equipment/Accessories :
- Control Unit in pressure-resistant housing, 400 V
f. NIROSTAR 2000-A/B ATEX application
- Dry run protection 60°C
- Trolley KOMPAKT

Complete unit ATEX class EX II 2/2G Ex IIB T2 Gb/Gb +5°C<Ta<+40°C

Dimensions 760-1000-1100x490x510 mm
weight 46,50 kg

Art. Nr. 13248136432A

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 4 bar
Inlet/outlet 1" mt
Impeller Neoprene® (CR) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 3,8 A
Starting capacitor 40 µF
Operating capacitor 16 µF
rotation max. 1400 min-1
Material motorshaft 1.4104
Protection class IP55
Motor protection (thermal) 130
weight 10,5 kg

Art. Nr. 13248137432A

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 4 bar
Inlet/outlet 1" mt
Impeller Neoprene® (CR) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 1,1 A
rotation max. 1400 min-1
Material motorshaft 1.4104
Protection class IP55
weight 10,5 kg

Art. Nr. 13248116431A

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 4 bar
Inlet/outlet 1" mt
Impeller Neoprene® (CR) , Bush material stainless steel (1.4404)
Shaft sealing ring Perbunan® (NBR)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 4 A
Starting capacitor 40 µF
Operating capacitor 20 µF
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP55
Motor protection (thermal) 130
weight 10,5 kg

Art. Nr. 13248137431A

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 4 bar
Inlet/outlet 1" mt
Impeller Neoprene® (CR) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 1,4 A
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP55
weight 10,5 kg

Art. Nr. 13348256352

Impellerpump
flow rate max. litres 120 l/min
flow rate max. m³ 7,2 m³/h
max. pressure 2,5 bar
Inlet/outlet 1 ¼“ mt
Impeller Neoprene® (CR) , Bush material stainless steell (1.4404)
Mechanical seal Car/Cer/Viton®
Material pump housing stainless steel 1.4404
With swing stopper and fixing srew

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,90 kW, Rated current (AC) 6,2 A
Starting capacitor 70 µF, Operating capacitor 30 µF
rotation max. 1400 min-1
Material motorshaft 1.4404
Protection class IP55
Rotation direction left/right , Switch L/R
weight 17,2 kg

Art. Nr. 13348257342

Impellerpump
flow rate max. litres 120 l/min
flow rate max. m³ 7,2 m³/h
max. pressure 2,5 bar
Inlet/outlet 1 ¼“ mt
Impeller Neoprene® (CR) , Bush material stainless steell (1.4404)
Mechanical seal Car/Cer/Viton®
Material pump housing stainless steel 1.4404
With swing stopper and fixing srew

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,75 kW, Rated current (AC) 3,03 A
rotation max. 1400 min-1
Material motorshaft 1.4404
Protection class IP55 , IE3
Rotation direction left/right , Switch L/R
weight 17,7 kg

Art. Nr. 13348256533

Impellerpump
flow rate max. litres 80 l/min
flow rate max. m³ 4,8 m³/h
max. pressure 2,0 bar
Inlet/outlet 1 ¼“ mt
Impeller Neoprene® (CR) , Bush material stainless steell (1.4404)
Mechanical seal Car/Cer/Viton
Material pump housing stainless steell 1.4404
With swing stopper and fixing screw

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 4,4 A
Starting capacitor 70 µF, Operating capacitor 16 µF
rotation max. 900 min-1
Material motorshaft 1.4404
Protection class IP55
Rotation direction left/right , Switch L/R
weight 17,2 kg

Art. Nr. 13348257543

Impellerpump
flow rate max. litres 80 l/min
flow rate max. m³ 4,8 m³/h
max. pressure 2,0 bar
Inlet/outlet 1 ¼“ mt
Impeller Neoprene® (CR), Bush material stainless steell (1.4404)
Mechanical seal Car/Cer/Viton
Material pump housing stainless steell 1.4404
With swing stopper and fixing screw

Electric motor
rotation max. 900 min-1, Nominal frequency 50 Hz
Nominal power 0,75 kW, Rated current (AC) 2,1 A
rotation max. 900 min-1
Material motorshaft 1.4404
Protection class IP55 , IE3
Rotation direction left/right , Switch L/R
weight 17,7 kg

Art. Nr. 190014NE

Impellerpump
flow rate max. litres 96 l/min
flow rate max. m³ 5,76 m³/h
max. pressure 3 bar
Inlet/outlet 1 ¼“ mt
Impeller Neoprene® (CR)
Mechanical seal Gra/Cer/EPDM®
Material pump housing stainless steel 1.4401

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,75 kW, Rated current (AC) 7,1 A
rotation max. 1400 min-1
Rotation direction left/right
Protection class IP55 , 2 m cable with plug
weight 14,5 kg

Art. Nr. 190014NV

Impellerpump
flow rate max. litres 96 l/min
flow rate max. m³ 5,76 m³/h
max. pressure 3 bar
Inlet/outlet 1 ¼“ mt
impeller Neoprene® (CR)
Mechanical seal Viton® (FKM)
Material pump housing stainless steel 1.4401

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,75 kW, Rated current (AC) 7,1 A
rotation max. 1400 min-1
Switch L/R , 2 m cable with plug
Protection class IP55
weight 14,5 kg

Art. Nr. 190013

Impellerpump
flow rate max. litres 96 l/min
flow rate max. m³ 5,76 m³/h
max. pressure 3 bar
Inlet/outlet 1 ¼“ mt
impeller Neoprene® (CR)
Mechanical seal Perbunan® (NBR)
Material pump housing stainless steel 1.4401

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,75 kW, Rated current (AC) 7,1 A
rotation max. 1400 min-1
Switch L/R , 2 m cable wiith plug
Protection class IP55
weight 15 kg

Art. Nr. 13348237342

Impellerpumpe
flow rate max. litres 96 l/min
flow rate max. m³ 5,76 m³/h
max. pressure 3,0 bar
Inlet/outlet 1¼" aG
Impeller Neoprene® (CR)
Mechanical seal Vidia/Viton
Material pump housing Edelstahl 1.4401

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,75 kW, Rated current (AC) 2,1 A
rotation max. 1400 min-1
Rotation direction left/right , 4 m cable without plug
Protection class IP55
weight 15 kg

Art. Nr. 190040NV

Impellerpump
flow rate max. litres 115 l/min
flow rate max. m³ 6,9 m³/h
max. pressure 2,4 bar
Inlet/outlet 1 ½“ mt
Impeller Neoprene® (CR)
Mechanical seal Viton® (FKM)
Material pump housing stainless steel 1.4301

Hydraulic motor
rotation max. 175 - 900 min-1
Oil pressure 100 - 120 bar
Oil quantity 0,05 l per rotation (45 l/min. for 900 rotations)
weight 13 kg

Art. Nr. 190020DN50

Impellerpump
flow rate max. litres 115 l/min
flow rate max. m³ 6,9 m³/h
max. pressure 3,0 bar
Inlet/outlet DIN 50 milwinding (DIN 11851)
Impeller Neoprene® (CR), mechanical seal Widia/Widia/ Viton
Material pump housing stainless steel 1.4301

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 1,5 kW, Rated current (AC) 4,1 A
rotation max. 900 min-1
Protection class IP55 , Rotation direction left/right
4 m cable without plug
weight 19,5 kg

Art. Nr. 190060TRICL

Impellerpump
flow rate max. litres 300 l/min
flow rate max. m³ 18 m³/h
max. pressure 2,0 bar
Inlet/outlet 2" Tri Clamp
Impeller Neoprene® (CR)
Mechanical seal Vidia/Vidia/Viton
Material pump housing stainless steel 1.4301

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 1,5 kW, Rated current (AC) 6,0 A
rotation max. 700 min-1
Switch L/R , 4 m cable without plug
Protection class IP55
weight 30 kg

Art. Nr. 190082

Impellerpump
flow rate max. litres 300 l/min
flow rate max. m³ 18 m³/h
max. pressure 2,0 bar
Inlet/outlet 2" mt
Impeller Neoprene® (CR)
Mechanical seal Widia/Widia/Viton
Material pump housing stainless steel 1.4301

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 1,5 kW, Rated current (AC) 6,0 A
rotation max. 700 min-1
Switch L/R , 4 m cable without plug
Protection class IP55
weight 30 kg

Art. Nr. 190083

Impellerpumpe
flow rate max. litres 375 l/min
flow rate max. m³ 22,5 m³/h
max. pressure 2,0 bar
Inlet/outlet 2" aG
Impeller Neoprene® (CR)
Mechanical seal Widia/Widia/Viton
Material pump housing Edelstahl 1.4301

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 1,87 kW, Rated current (AC) 5,5 A
rotation max. 900 min-1
Switch L/R , 4 m Kabel, ohne Stecker
Protection class IP55
weight 30 kg

Art. Nr. 190096

Impellerpump
flow rate max. litres 730 l/min
flow rate max. m³ 43,8 m³/h
max. pressure 2,0 bar
Inlet/outlet 3" mt
Impeller Neoprene® (CR)
Mechanical seal Widia/Widia/Viton
Material pump housing stainless steel 1.4301

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 3,5 kW, Rated current (AC) 8,2 A
rotation max. 600 min-1, Protection class IP55
Electrical connection Control board , without cable and plug
weight 70 kg

Art. Nr. 13128126322

Impellerpump
flow rate max. litres 15 l/min
flow rate max. m³ 0,9 m³/h
max. pressure 3 bar
Inlet/outlet 3/4" mt
Impeller EPDM , Bush material stainless steel (1.4404)
Shaft sealing ring EPDM
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 3,2 A
Starting capacitor 40 µF
Operating capacitor 16 µF
rotation max. 1400 min-1
Material motorshaft 1.4104
Protection class IP55
Motor protection (thermal) 130
weight 9,8 kg

Art. Nr. 13128127322

Impellerpump
flow rate max. litres 15 l/min
flow rate max. m³ 0,9 m³/h
max. pressure 3 bar
Inlet/outlet 3/4" mt
Impeller EPDM , Bush material stainless steel (1.4404)
Shaft sealing ring EPDM
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 1,15 A
rotation max. 1400 min-1
Material motorshaft 1.4404
Protection class IP55
weight 9,8 kg

Art. Nr. 13128126321

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 3 bar
Inlet/outlet 3/4" mt
Impeller EPDM , Bush material stainless steel (1.4404)
Shaft sealing ring EPDM
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 3,2 A
Starting capacitor 40 µF
Operating capacitor 20 µF
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP55
Motor protection (thermal) 130
weight 9,8 kg

Art. Nr. 13128127321

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 3 bar
Inlet/outlet 3/4" mt
Impeller EPDM , Bush material stainless steel (1.4404)
Shaft sealing ring EPDM
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 1,1 A
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP55
weight 9,8 kg

Art. Nr. 13128127221

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 3 bar
Inlet/outlet 3/4" mt
Impeller EPDM , Bush material stainless steel (1.4404)
Shaft sealing ring EPDM with o-ring instead of spring
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 1,20 A
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP66

Equipment/Accessories :
- Control Unit in pressure-resistant housing, 400 V
f. NIROSTAR 2000-A/B ATEX application
- Dry run protection 60°C
- Trolley KOMPAKT

Complete unit ATEX class EX II 2/2G Ex IIB T3

Dimensions 760-1000-1100x490x510 mm
weight 46,5 kg

Art. Nr. 13128126921

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 3 bar
Inlet/outlet 3/4" mt
Impeller EPDM , Bush material stainless steel (1.4404)
Shaft sealing ring EPDM® with o-ring instead of spring
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 2,56 A
Starting capacitor 50 µF, Operating capacitor 16 µF
rotation max. 2860 min-1
Material motorshaft Hardened shaft 1.4028 (AISI420F)
Protection class IP66 , Operating mode S1

Equipment/Accessories :
- Control Unit in pressure-resistant housing, 230 V
f. NIROSTAR 2000-A/B ATEX application
- Dry run protection 60°C
- Trolley KOMPAKT

Complete unit ATEX class EX II 2/2G Ex IIB T3

Dimensions 760-1000-1100x490x510 mm
weight 46,5 kg

Art. Nr. 13128126422A

Impellerpump
flow rate max. litres 15 l/min
flow rate max. m³ 0,9 m³/h
max. pressure 3 bar
Inlet/outlet ¾ mt
Impeller EPDM , Bush material stainless steel (1.4404)
Shaft sealing ring EPDM®
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 3,2 A
Starting capacitor 40 µF
Operating capacitor 16 µF
rotation max. 1400 min-1
Material motorshaft 1.4104
Protection class IP55
Motor protection (thermal) yes
weight 10 kg

Art. Nr. 13128127422A

Impellerpump
flow rate max. litres 15 l/min
flow rate max. m³ 0,9 m³/h
max. pressure 3 bar
Inlet/outlet ¾ mt
Impeller EPDM , Bush material stainless steel (1.4404)
Shaft sealing ring EPDM®
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 1,15 A
rotation max. 1400 min-1
Material motorshaft 1.4104
Protection class IP55
weight 10 kg

Art. Nr. 13121126421A

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 3 bar
Inlet/outlet ¾ mt
Impeller EPDM , Bush material Polyamid
Shaft sealing ring EPDM®
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 3,2 A
Starting capacitor 40 µF
Operating capacitor 12,5 µF
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP55
Motor protection (thermal) yes
weight 10 kg

Art. Nr. 13128127421A

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 3 bar
Inlet/outlet ¾ mt
Impeller EPDM , Bush material stainless steel (1.4404)
Shaft sealing ring EPDM®
Material pump housing stainless steel 1.4404
Mit Pumpenträger

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 1,1 A
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP55
weight 10 kg

Art. Nr. 13228127332

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 3 bar
Inlet/outlet 1" mt
Impeller EPDM , Bush material stainless steel (1.4404)
Shaft sealing ring EPDM
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 1,6 A
rotation max. 1400 min-1
Material motorshaft 1.4404
Protection class IP55
weight 10,3 kg

Art. Nr. 13228126331

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 3 bar
Inlet/outlet 1" mt
Impeller EPDM , Bush material stainless steel (1.4404)
Shaft sealing ring EPDM
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 4,3 A
Starting capacitor 40 µF
Operating capacitor 20 µF
rotation max. 2800 min-1
Material motorshaft 1.4404
Protection class IP55
Motor protection (thermal) 130
weight 10,4 kg

Art. Nr. 13228127331

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 3 bar
Inlet/outlet 1" mt
Impeller EPDM , Bush material stainless steel (1.4404)
Shaft sealing ring EPDM
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 1,4 A
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP55
weight 10,3 kg

Art. Nr. 13228126931

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 3 bar
Inlet/outlet 1 " mt
Impeller EPDM Bush material stainless steel (1.4404)
Shaft sealing ring EPDM® with o-ring instead of spring
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 3,8 A
Starting capacitor 70 µF, Operating capacitor 30 µF
rotation max. 2800 min-1
Material motorshaft 1.4028 (AISI420F)
Protection class IP66 , Operating mode S1
2 m cable with plug (H07RN-F 4x1,5mm² / CEE-16A)

Equipment/Accessories :
- Control Unit in pressure-resistant housing, 230 V
f. NIROSTAR 2000-A/B ATEX application
- Dry run protection 60°C
- Trolley KOMPAKT

Complete unit ATEX class EX II 2/2G Ex h IIB T3

Dimensions 760-1000-1100x490x510 mm
weight 47 kg

Art. Nr. 13228127231

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 3 bar
Inlet/outlet 1 " mt
Impeller EPDM , Bush material stainless steel (1.4404)
Shaft sealing ring EPDM® with o-ring instead of spring
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 1,45 A
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP66 , Operating mode S1

Equipment/Accessories :
- Control Unit in pressure-resistant housing, 400 V
f. NIROSTAR 2000-A/B ATEX application
- Dry run protection 60°C
- Trolley KOMPAKT

Complete unit ATEX class EX II 2/2G Ex h IIB T3

Dimensions 760-1000-1100x490x510 mm
weight 47 kg

Art. Nr. 13228126432A

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 3 bar
Inlet/outlet 1" mt
Impeller EPDM , Bush material stainless steel (1.4404)
Shaft sealing ring EPDM®
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 3,8 A
Starting capacitor 40 µF
Operating capacitor 16 µF
rotation max. 1400 min-1
Material motorshaft 1.4104
Protection class IP55
Motor protection (thermal) 130
weight 10,5 kg

Art. Nr. 13228127432A

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 3 bar
Inlet/outlet 1" mt
Impeller EPDM , Bush material stainless steel (1.4404)
Shaft sealing ring EPDM®
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 1,1 A
rotation max. 1400 min-1
Material motorshaft 1.4104
Protection class IP55
weight 10,5 kg

Art. Nr. 13228136431A

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 3 bar
Inlet/outlet 1" mt
Impeller EPDM , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
With pump carrier

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 4 A
Starting capacitor 40 µF, Operating capacitor 20 µF
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP55
Motor protection (thermal) 130
weight 11 kg

Art. Nr. 13228126431A

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 3 bar
Inlet/outlet 1" mt
Impeller EPDM , Bush material stainless steel (1.4404)
Shaft sealing ring EPDM®
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 4 A
Starting capacitor 40 µF
Operating capacitor 20 µF
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP55
Motor protection (thermal) 130
weight 10,5 kg

Art. Nr. 13228127431A

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 3 bar
Inlet/outlet 1" mt
Impeller EPDM , Bush material stainless steel (1.4404)
Shaft sealing ring EPDM®
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 1,4 A
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP55
weight 10,5 kg

Art. Nr. 13328246352

Impellerpump
flow rate max. litres 120 l/min
flow rate max. m³ 7,2 m³/h
max. pressure 2,5 bar
Inlet/outlet 1 ¼“ mt
Impeller EPDM® , Bush material stainless steell (1.4404)
Mechanical seal Material Car/Cer/EPDM®
Material pump housing stainless steel 1.4404
With swing stopper and fixing srew

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,90 kW, Rated current (AC) 6,2 A
Starting capacitor 70 µF, Operating capacitor 30 µF
rotation max. 1400 min-1
Material motorshaft 1.4404
Protection class IP55
Rotation direction left/right , Switch L/R
weight 17,2 kg

Art. Nr. 13328247342

Impellerpump
flow rate max. litres 120 l/min
flow rate max. m³ 7,2 m³/h
max. pressure 2,5 bar
Inlet/outlet 1 ¼“ mt
Impeller EPDM® , Bush material stainless steell (1.4404)
Mechanical seal Car/Cer/EPDM®
Material pump housing stainless steel 1.4404
With swing stopper and fixing srew

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,75 kW, Rated current (AC) 3,03 A
rotation max. 1400 min-1
Material motorshaft 1.4404
Protection class IP55 , IE3
Rotation direction left/right , Switch L/R
weight 17,7 kg

Art. Nr. 13328246533

Impellerpump
flow rate max. litres 80 l/min
flow rate max. m³ 4,8 m³/h
max. pressure 2,0 bar
Inlet/outlet 1 ¼“ mt
Impeller EPDM®, Bush material stainless steell (1.4404)
Mechanical seal Car/Cer/EPDM
Material pump housing stainless steell 1.4404
With swing stopper and fixing screw

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 4,4 A
Starting capacitor 70 µF, Operating capacitor 16 µF
rotation max. 900 min-1
Material motorshaft 1.4404
Protection class IP55
Rotation direction left/right , Switch L/R
weight 17,2 kg

Art. Nr. 13328247543

Impellerpump
flow rate max. litres 80 l/min
flow rate max. m³ 4,8 m³/h
max. pressure 2,0 bar
Inlet/outlet 1 ¼“ mt
Impeller EPDM®, Bush material stainless steell (1.4404)
Mechanical seal Car/Cer/EPDM
Material pump housing stainless steell 1.4404
With swing stopper and fixing screw

Electric motor
rotation max. 900 min-1, Nominal frequency 50 Hz
Nominal power 0,75 kW, Rated current (AC) 2,1 A
rotation max. 900 min-1
Material motorshaft 1.4404
Protection class IP55 , IE3
Rotation direction left/right , Switch L/R
weight 17,7 kg

Art. Nr. 190014

Impellerpump
flow rate max. litres 96 l/min
flow rate max. m³ 5,76 m³/h
max. pressure 3,0 bar
Inlet/outlet 1¼" mt
Impeller EPDM®
Mechanical seal Viton® (FKM)
Material pump housing stainless steel 1.4401

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,75 kW, Rated current (AC) 7,1 A
rotation max. 1400 min-1
Rotation direction left/right
Protection class IP55 , 2 m cable with plug
weight 14 kg

Art. Nr. 13328237342

Impellerpump
flow rate max. litres 96 l/min
flow rate max. m³ 5,76 m³/h
max. pressure 3,0 bar
Inlet/outlet 1¼" mt
Impeller EPDM®
Mechanical seal Viton® (FKM)
Material pump housing stainless steel 1.4401

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,75 kW, Rated current (AC) 2,1 A
rotation max. 1400 min-1
Rotation direction left/right
Protection class IP55 , 4 m cable without plug
weight 13 kg

Art. Nr. 13328247542

Impellerpump
flow rate max. litres 96 l/min
flow rate max. m³ 5,76 m³/h
max. pressure 3,0 bar
Inlet/outlet 1¼" mt
Impeller EPDM®
Mechanical seal EPDM®
Material pump housing stainless steel 1.4401

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,75 kW, Rated current (AC) 2,1 A
rotation max. 1400 min-1
Rotation direction left/right
Protection class IP55 , 4 m cable without plug
weight 13 kg

Art. Nr. 190019

Impellerpump
flow rate max. litres 64 l/min
flow rate max. m³ 3,84 m³/h
max. pressure 3,0 bar
Inlet/outlet 1¼" mt
Impeller EPDM®
Mechanical seal Gra/Cer/EPDM®
Material pump housing stainless steel 1.4401

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,56 kW, Rated current (AC) 5,0 A
rotation max. 900 min-1
Rotation direction left/right
Protection class IP55 , 2 m cable with plug
weight 15 kg

Art. Nr. 190017E

Impellerpump
flow rate max. litres 64 l/min
flow rate max. m³ 3,84 m³/h
max. pressure 3,0 bar
Inlet/outlet 1¼" mt
Impeller EPDM®
Mechanical seal EPDM®
Material pump housing stainless steel 1.4401

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,56 kW, Rated current (AC) 1,7 A
rotation max. 900 min-1
Rotation direction left/right
Protection class IP55 , 4 m cable without plug
weight 13,5 kg

Art. Nr. 190034

Impellerpump
flow rate max. litres 166 l/min
flow rate max. m³ 9,96 m³/h
max. pressure 3,0 bar
Inlet/outlet 1½" mt
Impeller EPDM®
Mechanical seal EPDM®
Material pump housing stainless steel 1.4301

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 1,5 kW, Rated current (AC) 3,8 A
rotation max. 1400 min-1
Protection class IP55 , Rotation direction left/right
Electrical connection Control board , without cable and plug
weight 18 kg

Art. Nr. 190032

Impellerpump
flow rate max. litres 166 l/min
flow rate max. m³ 9,96 m³/h
max. pressure 3,0 bar
Inlet/outlet 1½" mt
Impeller EPDM®
Mechanical seal EPDM®
Material pump housing stainless steel 1.4301

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 1,5 kW, Rated current (AC) 3,8 A
rotation max. 1400 min-1
Rotation direction left/right
Protection class IP55 , 4 m cable without plug
weight 20 kg

Art. Nr. 190023

Impellerpump
flow rate max. litres 115 l/min
flow rate max. m³ 6,9 m³/h
max. pressure 3 bar
Inlet/outlet 1 ½“ mt
Impeller EPDM®
Mechanical seal Gra/Cer/EPDM
Material pump housing stainless steel 1.4301

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 1,5 kW, Rated current (AC) 13 A
rotation max. 900 min-1
Switch L/R , 2 m cable with plug
Not suitable for bi-directional use!
Protection class IP55
weight 21 kg

Art. Nr. 190021

Impellerpump
flow rate max. litres 115 l/min
flow rate max. m³ 6,9 m³/h
max. pressure 3,0 bar
Inlet/outlet 1½" mt
Impeller EPDM®
Mechanical seal Vidia/Viton®
Material pump housing stainless steel 1.4301

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 1,5 kW, Rated current (AC) 13 A
rotation max. 900 min-1
Rotation direction left/right
Not suitable for bi-directional use!
Protection class IP55 , 2 m cable with plug
weight 21 kg

Art. Nr. 190031K

Impellerpump
flow rate max. litres 115 l/min
flow rate max. m³ 6,9 m³/h
max. pressure 3,0 bar
Inlet/outlet 1½" mt
Impeller EPDM®
Mechanical seal Cer/Gra/EPDM®
Material pump housing stainless steel 1.4301

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 1,5 kW, Rated current (AC) 4,1 A
Protection class IP55
Terminal board connection, without cable
weight 21 kg

Art. Nr. 190033

Impellerpump
flow rate max. litres 115 l/min
flow rate max. m³ 6,9 m³/h
max. pressure 3,0 bar
Inlet/outlet 1½" mt
Impeller EPDM®
Mechanical seal EPDM®
Material pump housing stainless steel 1.4301

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 1,5 kW, Rated current (AC) 4,1 A
rotation max. 900 min-1
Rotation direction left/right
Protection class IP55 , 4 m cable without plug
weight 19 kg

Art. Nr. 190041EE

Impellerpump
flow rate max. litres 375 l/min
flow rate max. m³ 22,5 m³/h
max. pressure 1,6 bar
Inlet/outlet 2" mt
Impeller EPDM®
Mechanical seal Cer/Gra/EPDM
Material pump housing stainless steell 1.4301

Hydraulic motor
rotation max. 175 - 900 min-1
0,05 l oil per rotation (45 liter/min. for 900 rotations)
oil pressure 100 - 120 bar
weight 18 kg

Art. Nr. 190059

Impellerpump
flow rate max. litres 300 l/min
flow rate max. m³ 18 m³/h
max. pressure 2 bar
Inlet/outlet 2" mt
Impeller EPDM®
Mechanical seal Perbunan® (NBR)
Material pump housing stainless steel 1.4301

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 1,5 kW, Rated current (AC) 6,0 A
rotation max. 700 min-1
Rotation direction left/right , 4 m cable without plug
Protection class IP55
weight 31,5 kg

Art. Nr. 190062

Impellerpump
flow rate max. litres 300 l/min
flow rate max. m³ 18 m³/h
max. pressure 2 bar
Inlet/outlet 2" mt
Impeller EPDM®
Mechanical seal EPDM®
Material pump housing stainless steel 1.4301

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 1,5 kW, Rated current (AC) 6,0 A
rotation max. 700 min-1
Rotation direction left/right
Protection class IP55
4 m cable without plug
weight 31 kg

Art. Nr. 190081

Impellerpump
flow rate max. litres 375 l/min
flow rate max. m³ 22,5 m³/h
max. pressure 2 bar
Inlet/outlet 2" mt
Impeller EPDM®
Mechanical seal EPDM®
Material pump housing stainless steel 1.4301

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 1,87 kW, Rated current (AC) 5,5 A
rotation max. 900 min-1
Rotation direction left/right , 4 m cable without plug
Protection class IP55
weight 30 kg

Art. Nr. 190064

Impellerpump
flow rate max. litres 375 l/min
flow rate max. m³ 22,5 m³/h
max. pressure 2 bar
Inlet/outlet 2" mt
Impeller EPDM®
Mechanical seal EPDM®
Material pump housing stainless steel 1.4301
Mounted on pump trolley

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 1,87 kW, Rated current (AC) 5,5 A
With mechanical speed variator , rotation max. 175 - 900 min-1
Control box CE with dry run protection
Protection class IP55
weight 66 kg

Art. Nr. 190042EPDM

Impellerpump
flow rate max. litres 730 l/min
flow rate max. m³ 43,8 m³/h
max. pressure 1,8 bar
Inlet/outlet 3" mt
Impeller EPDM®
Mechanical seal EPDM®
Material pump housing stainless steel 1.4301

Hydraulic motor
rotation max. 150 - 600 min-1
oil quantity 0,05 l per rotation (30 l/min. for 600 rotations)
Oil pressure 100 - 120 bar
weight 21 kg

Art. Nr. 190061

Impellerpump
flow rate max. litres 730 l/min
flow rate max. m³ 43,8 m³/h
max. pressure 2 bar
Inlet/outlet 3" mt
Impeller EPDM®
Mechanical seal EPDM®
Material pump housing stainless steel 1.4301

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 3,5 kW, Rated current (AC) 8,2 A
rotation max. 600 min-1
Protection class IP55 , Rotation direction left/right
Electrical connection Control board , Without cable and plug
weight 69 kg

Art. Nr. 190063

Impellerpump
flow rate max. litres 600 l/min
flow rate max. m³ 36 m³/h
max. pressure 2 bar
Inlet/outlet 3" mt
Impeller EPDM®
Mechanical seal Viton® (FKM)
Material pump housing stainless steel 1.4301

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 3,3 kW, Rated current (AC) 9,5 A
rotation max. 470 min-1
Rotation direction left/right
Protection class IP55 , without cable and plug
weight 68 kg

Art. Nr. 13191136321

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 3 bar
Inlet/outlet ¾" mt
Impeller TPU , Bush material polyamide bush
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steell 1.4404

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 3,2 A
Starting capacitor 40 µF
Operating capacitor 20 µF
rotation max. 2800 min-1Material motorshaft 1.4104
Protection class IP55
Motor protection (thermal) 130
weight 9,8 kg

Art. Nr. 13191116321

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 3 bar
Inlet/outlet ¾" mt
Impeller TPU , Bush material polyamide bush
Shaft sealing ring Perbunan® (NBR)
Material pump housing stainless steell 1.4404

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 3,2 A
Starting capacitor 40 µF
Operating capacitor 20 µF
rotation max. 2800 min-1Material motorshaft 1.4104
Protection class IP55
Motor protection (thermal) 130
weight 9,8 kg

Art. Nr. 13291136331

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 5 bar
Inlet/outlet
Impeller TPU , Bush material polyamide bush
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 230 VNominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 4,3 A
Starting capacitor 40 µF
Operating capacitor 20 µF
rotation max. 2800 min-1
Material motorshaft 1.4404
Protection class IP55
Motor protection (thermal) 130
weight 10,4 kg

Art. Nr. 13291132521A

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 5 bar
Inlet/outlet 1" mt
Impeller thermoplastic (no bi-directional use), Bush material polyamide bush
Shaft sealing ring Viton® (FKM)
Temperature max. 60 °C
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor
Voltage (DC) 24 V
Nominal power 0,6/0,8 kW, Rated current (DC) 36/47 A
rotation max. 3000 min-1
Motorshaft N-WE 14x30
Protection class IP44 , Operating mode S2
Electrical connection Control board
weight 10,6 kg

Art. Nr. 13291132421A

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 5 bar
Inlet/outlet 1" mt
Impeller thermoplastic (no bi-directional use) , Bush material polyamide bush
Shaft sealing ring Viton® (FKM)
Temperature max. 60 °C
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor CEM
Voltage (DC) 24 V
Nominal power 0,37 kW, Rated current (DC) 17 A
rotation max. 3000 min-1
Motorshaft N-WE 14x30mm
Protection class IP55 , Operating mode S1
Electrical connection Control board
weight 10,6 kg

Art. Nr. 13131136322

Impellerpump
flow rate max. litres 15 l/min
flow rate max. m³ 0,9 m³/h
max. pressure 3 bar
Inlet/outlet ¾" mt
Impeller Viton® (FKM) , Bush material Polyamid
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 3,2 A
Starting capacitor 40 µF
Operating capacitor 16 µF
rotation max. 1400 min-1
Material motorshaft 1.4104
Protection class IP55
Motor protection (thermal) 130
weight 9,8 kg

Art. Nr. 13131137322

Impellerpump
flow rate max. litres 15 l/min
flow rate max. m³ 0,9 m³/h
max. pressure 3 bar
Inlet/outlet ¾" mt
Impeller Viton® (FKM) , Bush material Polyamid
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 1,15 A
rotation max. 1400 min-1
Material motorshaft 1.4404
Protection class IP55
weight 9,8 kg

Art. Nr. 13138136321

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 3 bar
Inlet/outlet 3/4" mt
Impeller Viton® (FKM) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 3,2 A
Starting capacitor 40 µF
Operating capacitor 20 µF
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP55
Motor protection (thermal) 130
weight 9,8 kg

Art. Nr. 13131137321

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 3 bar
Inlet/outlet ¾" mt
Impeller Viton® (FKM) , Bush material
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 1,1 A
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP55
weight 9,8 kg

Art. Nr. 13138137221

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 3 bar
Inlet/outlet 3/4" mt
Impeller Viton® (FKM) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM) with o-ring instead of spring
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 1,20 A
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP66

Equipment/Accessories :
- Control Unit in pressure-resistant housing, 400 V
f. NIROSTAR 2000-A/B ATEX application
- Dry run protection 60°C
- Trolley KOMPAKT

Complete unit ATEX class EX II 2/2G Ex IIB T2 Gb/Gb +5°C<Ta<+40°C cm

Dimensions (LxWxH) 400 x 300 x 200 mm
weight 46,50 kg

Art. Nr. 13138136921

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 3 bar
Inlet/outlet 3/4" mt
Impeller Viton® (FKM) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM) with o-ring instead of spring
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 2,56 A
Starting capacitor 50 µF
rotation max. 2860 min-1
Material motorshaft Hardened shaft 1.4028 (AISI420F)
Protection class IP66

Equipment/Accessories :
- Control Unit in pressure-resistant housing, 230 V
f. NIROSTAR 2000-A/B ATEX application
- Dry run protection 60°C
- Trolley KOMPAKT

Complete unit ATEX class EX II 2/2G Ex IIB T2 Gb/Gb +5°C<Ta<+40°

Dimensions 760-1000-1100x490x510 mm
weight 46,5 kg

Art. Nr. 13138136422A

Impellerpump
flow rate max. litres 15 l/min
flow rate max. m³ 0,9 m³/h
max. pressure 3 bar
Inlet/outlet ¾" mt
Impeller Viton® (FKM) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 3,2 A
Starting capacitor 40 µF
Operating capacitor 16 µF
rotation max. 1400 min-1
Material motorshaft 1.4104
Protection class IP55
Motor protection (thermal) yes
weight 10 kg

Art. Nr. 13138131412A

Impellerpump
flow rate max. litres 15 l/min
flow rate max. m³ 0,9 m³/h
max. pressure 3 bar
Inlet/outlet ¾" mt
Impeller Viton® (FKM) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor CEM
Voltage (DC) 12 V
Nominal power 0,25 kW
rotation max. 1500 min-1
Motorshaft N-WE 14x30mm
Protection class IP55 , Operating mode S1
Electrical connection Control board
Without cable and plug
Colour RAL 9005 black
weight 10 kg

Art. Nr. 13131131412A

Impellerpump
flow rate max. litres 15 l/min
flow rate max. m³ 0,9 m³/h
max. pressure 3 bar
Inlet/outlet ¾" mt
Impeller Viton® (FKM) , Bush material Polyamid
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor CEM
Voltage (DC) 12 V
Nominal power 0,25 kW
Motorshaft N-WE 14x30mm
Protection class IP55 , Operating mode S1
Electrical connection Control board
Without cable and plug
Colour RAL 9005 black
weight 10 kg

Art. Nr. 13138132412A

Impellerpump
flow rate max. litres 15 l/min
flow rate max. m³ 0,9 m³/h
max. pressure 3 bar
Inlet/outlet ¾" mt
Impeller Viton® (FKM) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor CEM
Voltage (DC) 24 V
Nominal power 0,25 kW, Rated current (DC) 16 A
rotation max. 1500 min-1
Motorshaft N-WE 14x30mm
Protection class IP55 , Operating mode S1
Electrical connection Control board
Colour RAL 9005 black
weight 10 kg

Art. Nr. 13131132412A

Impellerpump
flow rate max. litres 15 l/min
flow rate max. m³ 0,9 m³/h
max. pressure 3 bar
Inlet/outlet ¾" mt
Impeller Viton® (FKM) , Bush material Polyamid
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor CEM
Voltage (DC) 24 V
Nominal power 0,25 kW, Rated current (DC) 16 A
rotation max. 1500 min-1
Motorshaft N-WE 14x30mm
Protection class IP55 , Operating mode S1
Electrical connection Control board
Colour RAL 9005 black
weight 10 kg

Art. Nr. 13131136421A

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 3 bar
Inlet/outlet ¾" mt
Impeller Viton® (FKM) , Bush material Polyamid
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 3,2 A
Starting capacitor 40 µF
Operating capacitor 12,5 µF
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP55
Motor protection (thermal) yes
weight 10 kg

Art. Nr. 13138137421A

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 3 bar
Inlet/outlet ¾" mt
Impeller Viton® (FKM) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,37 kW, Rated current (AC) 1,1 A
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP55
weight 10 kg

Art. Nr. 13138132411A

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 3 bar
Inlet/outlet ¾" mt
Impeller Viton® (FKM) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor CEM
Voltage (DC) 24 V
Nominal power 0,25 kW, Rated current (DC) 12 A
rotation max. 3000 min-1
Motorshaft N-WE 14x30mm
Protection class IP55 , Operating mode S1
Electrical connection Control board
Without cable and plug
Colour RAL 9005 black
weight 10 kg

Art. Nr. 13231136332

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 3 bar
Inlet/outlet 1" mt
Impeller Viton® (FKM) , Bush material Polyamid
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 3,8 A
Starting capacitor 40 µF
Operating capacitor 16 µF
rotation max. 1400 min-1
Material motorshaft 1.4404
Protection class IP55
Motor protection (thermal) 130
weight 10,4 kg

Art. Nr. 13238137332

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 3 bar
Inlet/outlet 1" mt
Impeller Viton® (FKM) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4401

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 1,6 A
rotation max. 1400 min-1
Material motorshaft 1.4404
Protection class IP55
weight 10,3 kg

Art. Nr. 13238136331

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 3 bar
Inlet/outlet 1" mt
Impeller Viton® (FKM) ,Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 4,3 A
Starting capacitor 40 µF
Operating capacitor 20 µF
rotation max. 2800 min-1
Material motorshaft 1.4404
Protection class IP55
Motor protection (thermal) 130
weight 10,4 kg

Art. Nr. 13239136331

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 3 bar
Inlet/outlet 1" mt
Impeller Viton® (FKM) , Bush material stainless steel (1.4404) spec. bush
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4401

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 4,3 A
Starting capacitor 40 µF
Operating capacitor 20 µF
rotation max. 2800 min-1
Material motorshaft 1.4404
Protection class IP55
Motor protection (thermal) 130
weight 10,4 kg

Art. Nr. 13238136931

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 3 bar
Inlet/outlet 1 " mt
Impeller Viton® (FKM) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM) with o-ring instead of spring
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 3,8 A
Starting capacitor 70 µF, Operating capacitor 30 µF
rotation max. 2800 min-1
Material motorshaft 1.4028 (AISI420F)
Protection class IP66

Equipment/Accessories :
- Control Unit in pressure-resistant housing, 230 V
f. NIROSTAR 2000-A/B ATEX application
- Dry run protection 60°C
- Trolley KOMPAKT

Complete unit ATEX class EX II 2/2G Ex IIB T2 Gb/Gb +5°C<Ta<+40°C

Dimensions 760-1000-1100x490x510 mm
weight 46,5 kg

Art. Nr. 13238137231

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 3 bar
Inlet/outlet 1 " mt
Impeller Viton® (FKM) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM) with o-ring instead of spring
Material pump housing stainless steel 1.4404

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 1,45 A
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP66

Equipment/Accessories :
- Control Unit in pressure-resistant housing, 400 V
f. NIROSTAR 2000-A/B ATEX application
- Dry run protection 60°C
- Trolley KOMPAKT

Complete unit ATEX class EX II 2/2G Ex IIB T2 Gb/Gb +5°C<Ta<+40°C

Dimensions 760-1000-1100x490x510 mm
weight 46,5 kg

Art. Nr. 13238136432A

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 3 bar
Inlet/outlet 1" mt
Impeller Viton® (FKM) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,55 kW. Rated current (AC) 3,8 A
Starting capacitor 40 µF
Operating capacitor 16 µF
rotation max. 1400 min-1
Material motorshaft 1.4104
Protection class IP55
Motor protection (thermal) 130
weight 10,5 kg

Art. Nr. 13238137432A

Impellerpump
flow rate max. litres 30 l/min
flow rate max. m³ 1,8 m³/h
max. pressure 3 bar
Inlet/outlet 1" mt
Impeller Viton® (FKM) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 1,1 A
rotation max. 1400 min-1
Material motorshaft 1.4104
Protection class IP55
weight 10,5 kg

Art. Nr. 13238136431A

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 3 bar
Inlet/outlet 1" mt
Impeller Viton® (FKM) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 4 A
Starting capacitor 40 µF
Operating capacitor 20 µF
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP55
Motor protection (thermal) 130
weight 10,5 kg

Art. Nr. 13239136431A

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 3 bar
Inlet/outlet 1" mt
Impeller Viton® (FKM) , Bush material stainless steel (1.4404) spec. bush
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor
Voltage (AC) 230 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 4 A
Starting capacitor 40 µF
Operating capacitor 20 µF
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP55
Motor protection (thermal) 130
weight 10,8 kg

Art. Nr. 13238137431A

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 3 bar
Inlet/outlet 1" mt
Impeller Viton® (FKM) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor
Voltage (AC) 400 V, Nominal frequency 50 Hz
Nominal power 0,55 kW, Rated current (AC) 1,4 A
rotation max. 2800 min-1
Material motorshaft 1.4104
Protection class IP55
weight 10,5 kg

Art. Nr. 13238132521A

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 3 bar
Inlet/outlet 1" mt
Impeller Viton® (FKM) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor
Voltage (DC) 24 V
Nominal power 0,6/0,8 kW, Rated current (DC) 36/47 A
rotation max. 3000 min-1
Motorshaft N-WE 14x30
Protection class IP44 , Operating mode S2
Electrical connection Control board
weight 10,6 kg

Art. Nr. 13238132421A

Impellerpump
flow rate max. litres 60 l/min
flow rate max. m³ 3,6 m³/h
max. pressure 3 bar
Inlet/outlet 1" mt
Impeller Viton® (FKM) , Bush material stainless steel (1.4404)
Shaft sealing ring Viton® (FKM)
Material pump housing stainless steel 1.4404
With pump carrier

Electric motor CEM
Voltage (DC) 24 V
Nominal power 0,37 kW, Rated current (DC) 17 A
rotation max. 3000 min-1
Motorshaft N-WE 14x30mm
Protection class IP55 , Operating mode S1
Electrical connection Control board
weight 10,6 kg
